Cama de Parto Electrónica, Motores de Columna
CAMAS DE PARTO Y MESAS DE GINECOLOGÍAOBSTETRA
Cama de Parto Electrónica, Motores de Columna
- Electronic adjustments of backrest, legrest, height-up & down positions
- Electrical operated Trendelenburg and Reverse Trendelenburg positions.
- Metal parts coated with zinc phosphate and varnished with an electrostatic epoxy-polyester powder
- Easily cleanable, 3-section (HPL) compact laminate mattress surface.
- X-Ray permeable lying surface
- Converting to Bed
- Removable headboard and footboard made of hygienic PP materials.
- Tuck-away side rails made of hygienic PP materials
- IV pole receptacles and on the two corners of the headboard
- Rotating protective bumpers at all (four) corners of the bed
- Height adjustable IV pole
- Pair drainage hooks at both sides of the bed.
- Stainless steel accessory rails
- 125 mm diameter swivel castors with central locking system and directional lock
- Nurse control panel
- Electronically CPR (Reset)
- Equipped with powerful column motors
- Two-piece ABS plastic covered lower chassis
- Stainless steel accessories corrosion resistant
- Removable stainless steel fluid basin
- Adjustable patient hand grips
- Sliding foot section mechanism
- Angle indicators on the side rails for the backrest, Trendelenburg and Reverse Trendelenburg positions.
- Back up battery for non-stop operation in case of power failure.
- Foam mattress of 12 cm thickness and 28 kg/m3 suitable for lying surface with antibacterial & flame retardant cover
- Adjustable Leg supports
- Squatting Bar
- Upholstered heel Supports (foot support)
- Manual CPR for the backrest
- Accessory Trolley
- Control panels embedded on side rails (optional)
- Twin castors of 150 mm diameter (optional)
- Foot switch (optional)
| Backrest Angle | 0°-67° |
|---|---|
| Pelvic Angle | 0°-27° |
| Trendelenburg Angle | 0°-20° |
| Reverse Trendelenburg Angle | 0°-20° |
| External Dimensions | 109×209 cm |
| Product Weight (Empty) | 140 kg |
| Bed Surface (Extended) | 85×191 cm |
| Bed Surface (Retracted) | 85×144 cm |
| Height (without Mattress) | 60-100 cm |
| Mattress Thickness (Backrest and Pelvic Sections) | 12 cm |
| Castor Diameter | 125 mm |
| Safe Working Load Capacity | 250 kg |
